Description
Fixed power size 4
Aluminium
Scissor / Steel
Electro hold open or swing free, closing, latching speed
80kgs (door mount pull / door mount push), 60kgs (door mount push)
1100mm (door mount pull), 950mm (door mount pull / door mount push)
24Vdc
Successfully tested in accordance with the requirements of BS EN 1155: 1997
Successfully fire tested in accordance with the requirements of BS EN1634-1, suitable for use on 30, 60, 90 and 120 minute timber fire doors
CE Marked (Certificate AE7863)
UKCA marked (Certificate AE7860)
CERTIFIRE approved (Certificate CF6104)
2-year guarantee
Semi-radiused
Square
Silver (SE)
Satin Stainless Steel (SSS)
GTIN:
5055360000000 MPN:
VDC-EMS04-HO/SF-SQ-SSS SKU:
VDC-EMS04-HO/SF-SQ-SSS
